High-Pressure Reinforced L-Type Seal
Home / Products / L-Shaped Oil Seal Ring / High-Pressure Reinforced L-Type Seal
  • High-Pressure Reinforced L-Type Seal
  • High-Pressure Reinforced L-Type Seal
Ningguo Jnsseals Sealing Technology Co., Ltd.

High-Pressure Reinforced L-Type Seal

As the heavy-duty model in the L-series, the A-2-004 is built to withstand high-pressure shocks up to 1800N. Its robust 24.5mm OD and 2410 tube compatibility offer ultimate safety for heavy lifting and pressing equipment.
Features: Maximum 1800N load capacity; Anti-extrusion design; Thickened lips for high-thrust environments and long service life.

Contact Us
PREV：No previous article NEXT：Medium-Duty Balanced L-Type Oil Seal
  • Product Details
Product Specifications 10*24*6
OD 24.5
ID 9.2
H 6
O-ring adapter 24*10
Design applicable pressure range 600-1800N
Steel pipe inner diameter * piston rod diameter 24*10
Product Materials NBR
Remark
Product Code A-2-004
